23.6 Inch 5MP BNC Security Monitor for HD-over-Coax Cameras

The SVD 23.6-inch security monitor is built for professional surveillance systems that need more than a basic HDMI display. It can show DVR or NVR output over HDMI, and it can also accept compatible HD-over-coax camera video directly over BNC.

Best For

• Retail counters, front desks, control rooms, and active monitoring desks
• Direct camera-to-monitor spot displays using compatible BNC video
• HD-over-coax systems using TVI, AHD, CVI, or CVBS cameras
• Installers who need a larger monitor for 4-camera to 9-camera layouts

Direct 5MP BNC Input

Unlike basic monitors with legacy CVBS-only BNC ports, this professional security monitor accepts HD-over-coax video directly. It supports HD-TVI up to 5MP, AHD up to 5MP, HD-CVI up to 4MP, and standard CVBS/960H analog video.

Flexible Inputs for Real Installations

Use HDMI for DVR, NVR, or PC output. Use the two BNC inputs for direct compatible camera feeds or analog video sources. Two BNC loop outputs let you pass the signal onward to another display or recorder when the job requires it.

Key Features

• Screen size: 23.6-inch, 16:9
• HDMI input: DVR, NVR, or PC viewing
• BNC inputs: 2 x BNC video inputs
• BNC outputs: 2 x looping outputs
• BNC formats: HD-TVI up to 5MP, AHD up to 5MP, HD-CVI up to 4MP, CVBS/960H
• Mounting: Removable stand and VESA mounting support
• Use case: DVR/NVR monitor, spot monitor, direct BNC camera display
• Certifications: FCC, CE, RoHS
• Support: California-based SVD support

Common Questions

Can I plug a 5MP BNC camera directly into this monitor?
Yes, for compatible HD-TVI and AHD cameras up to 5MP. It also supports HD-CVI up to 4MP and CVBS/960H analog video.

Does the monitor create split-screen views?
No. The DVR or NVR creates the split-screen layout, then sends it to the monitor over HDMI or another output.
