- 7 inch 1920x1200 resolution retina IPS screen and marvelous 323 ppi, and it is difficult to conscious of the granular sensation of a screen pixel.
- This tester has a strongly flexible protective sleeve with two flanks to protect the device. It not only enhances the comfort of your hand but also available prevent equipment from damage in fall. Built-in key-pressed backlight will make it easier to use in dark.
- Bulit-in Wifi module can be used as a tablet.You can install applications to work in diverse environments. Support H.265 decoding and debug 4K resolution IP Camera. Equipped with AHD,CVI,TVI,SDI module, supporting the most resolution for 4K, comprehensive work in monitor and debugs project.
- IP-Shortcut button test"procedure can quickly multi-subnet search for IP camera and the fast produce just need several seconds from accessing line to watching the picture.There are no complex IP address setting.It greatly increases work efficiency.
- Bulit-in a high-capacity lithium polymer battery. The full charging can provide an IP camera test over 10 hours or a power-supplied test about 2 hours. All give the credit to a high- capacity battery. The tester equipped 48V 25W POE power-supplied and 12V 3A power output, It can fulfill a temporary demand for power.
More simple, higher efficiency
CCTV tester enormously reduce work cost,and easy to use CCTV tester,our software engineers persist in adding,improving and consummating more complex procedure.We constant innovation to reach the original intention of the product.
Specifications:
Touch Screen:7" 1920x1200,323PPI,450cd/m2
Network: Gigabit network ports,support 10M/100M/1000M.Built-in WiFi, speed rate 150M
Digital network decoding: Hardware decoding,support watching H.265 IP camera video,the highest resolution is 4K 3840x2160
Coaxial analog video decoding: Support CVBS analog decoding,RS485/RS232 PTZ.Support AHD HD/ HD-CVI HD / HD-TVI HD analog video decoding, maximum support 4K 3840x2160 resolution,support coaxial video control
Coaxial HD digital video decoding: Support HD-SDI / 3G-SDI / EX-SDI HD video decoding
HDMI: Support HDMI signal input,maximum 1920x1080p.Support HDMI signal output,maximum 3840x2160p
Audio: Built-in loudspeaker,3.5mm audio signal input/output
Battery and charger: Built-in 57Wh lithium polymer battery.Configure 23W charger,the full charging time is about 4-5hours
Output power: Support POE, 48V,maximum output power about 25W,with overload protection and monitorable output status.Support 12V power output,maximum 3A,with overload protection and monitorable output status.Support 5V power output,maximum 2A
Input power: Support 12V and test input voltage status.Access POE and test voltage and power status
Cable tracer: An all-in-one digital and analog cable tracer,according to instrument mainframe send the audio signal to seek cable
Package Included:
1 x IP Camera Tester
1 x Power Output Cable
1 x RS485 Test Cable
1 x Audio Test Cable
1 x BNC Cable
1 x Crocodile Clip BNC Cable
1 x Cable Tracer
1 x Power Adaptor
3 x Straps
1 x Storage Bag
1 x Built-in English User Manual
